SeceuroDoor Insulated Industrial Door

SeceuroDoor 77 Range

The SeceuroDoor 77 range is the insulated version of the SeceuroDoor 75, using a double skinned steel lath in a galvanised finish as standard, but with the option of almost any RAL or BS colour. You can have a single or 3 phase motor drive with an inboard or direct drive motor unit providing a durable and reliable electric operation. Higher speed opening is also possible with a high speed motor. A quite unique insulated manually operated roller door with a 77mm deep steel section insulated, double skinned lath is available, the 77c.

With the additional weight of this curtain the maximum size is 5000mm wide and 4000mm high but this door has many applications where insulation and strength may be required usually in exposed locations or where the building is heated inside.

With the SeceuroDoor 75 you also have the option of a pedestrian wicket door inset into the main roller door curtain for ease of access if you have a lot of pedestrian daily traffic.

There is also the option of the perforated slats to provide 25% light and vision in the curtain in any section required or the whole curtain.

Galvanised insulated industrial door

The SeceuroDoor 77t is a relatively unique insulated roller shutter door on the UK market using a 77mm steel double skinned slat with a 15mm depth. It is a ‘continental’ style guide set up, meaning the guides are in line with the outer edge of the endplates which support the barrel and curtain. This means the installation is straightforward and very neat and easy when there may be a tight fit on site. It can be installed behind but also inbetween an opening easily and because the roller door uses a barrel motor the motor drive is inside the barrel and out of sight and out of the way.

It is very well priced for an insulated commercial roller door and can be powder coated to any colour of your choice including the guides and hood cover which would always be recommended with any insulated roller door installation

• Heat transmission performance for the 77 mm single slat profile 4.01 W/(m2 K)
• Max width 6000 mm
• Max height 3400 mm
• Max area 20 m2
• Can be powder coated any colour
• Standard guide angle is 75 mm x 75 mm
• Other sizes are available on request

Insulated industrial door

The SeceuroDoor 77 is an insulated version of the SeceuroDoor 75 using a double skinned steel lath in a galvanised finish as standard but with the option of almost any RAl or BS colour. You can have a single or 3 phase motor drive with an inboard or direct drive motor unit providing a durable and reliable electric operation.

• Heat transmission performance for the 77 mm single slat profile 4.01 W/(m2 K)
• Max width 6000 mm
• Max area 20 m2
• Your choice of motor
• Can be powder coated any colour
• Choice of 4 guide arrangement options
• Standard guide angle is 75 mm x 50 mm
• Other sizes are available on request

Manual Chain Operated

A quite unique insulated manually operated roller door with a 77mm deep steel section insulated, double skinned lath.

With the additional weight of this curtain the maximum size is 5000mm wide and 4000mm high but this door has many applications where insulation and strength may be required, gain in exposed locations or where the building is heated in any way.

• Max width 5500 mm
• Max height 5500 mm
• Max area 30 m2
• Can be powder coated any colour
• Choice of 4 guide arrangement options
• Standard guide angle is 75 mm x 50 mm
• Other sizes are available on request
• Vision option available
• Wind class rating: Class 3

Please see below for Bottom rails, Guide and Slat options
