Metador PASGuard 1
PAS24 Steel Doorsets
PAS 24 Certified Steel Doorset
Sizes up to 1284mm wide x 2400mm high
Material: Steel
Enquiry Form
Call Us
Email Us
Web Price From: £1,190.00
(Excluding VAT and £1,428.00 Inc. VAT)
Web Price From:
£1,190.00
(Excluding VAT and
£1,428.00
Inc. VAT)
NEED HELP? Call us on 01933 448 850
or click here to connect via our Live Chat
- Description
- Application
- Specification
- Installation
- Warranty
- Measure
Description
The PASGuard is a made to measure, double skinned steel, Secure by Design approved and PAS24 rated steel doorset providing certified security protection and suitable for residential and commercial applications where aesthetics might also be more relevant.
Available in over 200 RAL standard colours and also many wood effect and metallic finishes the door can also have pressed designs in the steel where required so you have a door label which isn’t just a flat steel exterior.
Available with a wide range of hardware options and vision panels this door is a great mid range security doorset for peace of mind in a proper construction and a tested ability to resist attack.
The door can be used for both external and internal applications and would typically include a multi point locking system approved for use with the PAS 24 standard.
Application
Any residential, commercial or industrial building requiring PAS24 as part of the door compliance with building regulations or insurance.
Typical applications might include entrance doors for apartments and flats and even houses, but also communal areas and social housing. Plant rooms, garage conversions, offices, retail outlets and any general building which is built new.
PAS24 is the preferred specification for enhanced security performance requirements for doorsets and windows in the UK.
It sets out the minimum doorset requirements and acceptable test criteria to resist attack from opportunistic crime.
Not only do these doors offer greater levels of security, they are also manufactured to higher standards with stronger overall integrity and components used and therefore always tend to have greater longevity through their durability.
Since 2015, part Q of the Building Regulations has required doors and windows fitted to new dwellings to meet the requirements of PAS24. Whilst this does not currently cover replacement doors and windows, the Defender PASguard is a clear choice to bring security and peace of mind to residents and property owners alike.
Specification
Maximum width for single door with fixing sub frame included: 1284mm
Maximum height for single door with fixing sub frame included: 2400mm
Security Rating: PAS 24 (Product Assessment Specification 24)
Door Leaf / Threshold
Anti-jemmy flange on the leadingedge (square edged option available)
• 1.5mm galvanised steel (upgrade: 1.5mm stainless steel, 304/316)
• Weld-free construction prevents premature failure
• Mineral wool core with internal strengtheners.
Standard DDA compliant chamfered threshold profile in 2mm stainless steel construction
Options for raised or extended cills, inward opening profiles with drainage or 4mm ramped design.
Integrated removable thresholds available.
Thermal Performance
Standard U-value: 2.2 W/m²K (upgradeable to 1.4 W/m²K with Thermaguard Technology).
Sub Frame
90mm single rebate frame in 2.0mm galvanised steel (stainless option available)
• Custom dimensions and alternative profiles (double rebated, face-fixed, ModuleX integral cloaking and more)
• Bolted corners for strength
• PASguard doorsets have been tested as both inward and outward opening configurations
• Threaded adjustors for easy installation (16+ fixings). Optional plain fixing plates
Hardware
Stainless steel ball bearing hinges (4+ per door, with security dogbolts)
• Extensive hardware range: locks, latches, handles, panic hardware, closers, and stays. Custom hardware integration available.
Over Panels and Side Panels
Designed to expand openings, these panels integrate seamlessly with Defender PASguard doorsets:
• Solid framed panels available with either fixed or removable centre panels
• PAS24 rated glazed side and overpanels with weathertight wedge-gasket seals. Available as
separate units or integrated with your doorset, utilising shared frame mullions and transoms for maximum strength and a premium look.
Upgrade Options
The PASGuard steel doorset can be acoustic rated if this is a requirement on site.
Fire rating options are also available up to 120 min for internal or external use.
Vision panels in custom sizes compliant with PAS24 are available alongside louvre ventilation panels where required.
Installation
Nearly all our steel doorsets are delivered completely factory assembled with all hardware and sub frames fitted ready for the easiest on site installation. The doorsets will be heavy and we can provide the weight before delivery if required but they will often need mechanical offloading or 2 or more people to handle on delivery and installation.
Installation instructions can be downloaded HERE
Warranty
The Metador guarantee includes:
The frame and door sets are given 15 years guarantee subject to correct door installation and maintenance.
All our Ironmongery has a 1-year guarantee subject to correct usage and maintenance The Marine Grade PPC finish is guaranteed for a period of 10 years subject to the cleaning and maintenance programme.
At Metador the Standard Powdercoat finish is guaranteed for a period of 1 year subject to the cleaning and maintenance programme.
Guarantee Coverage:
Metador will repair or at our option replace any goods sold by Samson Doors to you which are, shown to our reasonable satisfaction to have become defective within the warranty period stated above from the date of purchase.
Where we have supplied a product with an internal defective component, we will only replace the defective component within the product.
‘Defective’ goods are those which under correct usage, do not function properly because of a fault in materials, workmanship or design.
We will replace any goods that are found to be defective on delivery, when reported within 3 working days of receiving the delivery. Photo graphic evidence must be provided showing the defective goods on the pallet that they were delivered on.
Guarantee Exclusions:
With Metador, there are some situations in which the guarantee does not cover, these include damage caused by:
Abuse, unsuitable or lack of maintenance and any other neglect that might occur.
Harmful cleaning solvents that may be used to clean the door
Incorrect installation of the door
Damage to the paint finish of the door which may include, scratches, washing and paint protection.
Use of parts that are installed that are not advised by Metador
External impacts including weather
Repairs or fitting that have been supported by other persons
Fair wear and tear
It should be noted that for any guarantees or warranties to be valid, the cleaning and maintenance regime must be documented and recorded, confirming the frequency of maintenance along with all methods and products used. This must be submitted for any claim to be considered.
Claims Procedure:
The customer must contact Samson Doors or Metador in writing within 3 working days of the discovery of the defect, specifying the nature of the claim and defect.
On request, the customer must return the defective product to Metador Ltd at their cost for inspection.
Operation and Maintenance Manual can be downloadad here
Measure
A steel doorset is always ordered by the OVERALL dimensions including the door leaf and outer sub fixing frame with no tolerances allowed for. Most people would generally allow 5mm tolerance all the way around the door, but it all depends on how square or true your aperture is on site. This is up to your judgement based on the aperture quality.
This would mean if your structural opening size is measured as 1000mm width and 2100mm height the door and frame ought to be 990mm wide and 2090mm high with the frame and any threshold included.
Always measure the top, middle and bottom of your aperture width and the left and right hand side for the height and if possible do a measure to make sure the opening is square as well..
Always use millimetres for measuring as this is how we relay back the ordering dimensions to you for checking and approving a drawing for your order.
We will always send a drawing for approval before manufacturing commences.
