V 5030 SEL

High Speed Roller Doors

Wind Resistant High Speed Door

Material: Fabric
Gear Type: Roller Shutter
Enquiry Form
Call Us
Email Us

The quiet and quick Hormann V 5030 SEL, quintessential to areas which need to maintain a low noise level. The V 5030 SEL can reach optimum speeds of 3.0m/s (with the optional Hormann frequency converter control).

Quiet and quick
In halls with a low noise level, a door should cause little noise and also work quickly and reliably with strong drafts. That’s why the V 5030 SEL door type is equipped with spring steel wind protectors to give the curtain the necessary stability.

The speed of up to 3 m/s is achieved by the optional Hörmann AS 500 FU E frequency converter control.

Spring steel wind protector
Integrated into a pocket in the curtain with twin track rollers at the sides for a quiet door travel and improved resistance to higher wind pressure.

Door size
Width (LB) max. 5000 mm
Height (LH) max. 5000 mm

Speed* opening/closing
Standard control
BK 150 FUE H 2.0/0.8 m/s
Optional control
AS 500 FU E 3.0/0.8 m/s
*max., depending on the door size

Spring steel wind protectors with side rollers
Fabric/vision panel thickness 1.5/2.0 mm

Emergency opening
Crank handle
Automatic opening via UPS during power failure
(BS 150 FUE H USV, 230 V)

Curtain Colours
RAL 1018 Zinc Yellow
RAL 2004 Pure Orange
RAL 3002 Carmine Red
RAL 5010 Gentian Blue
RAL 7038 Agate Grey

Let us help you complete your order
Enquiry form Call us Email us
  • Specification
Door Type V 5015 SEL V 5030 SEL
Suitable Application Interior Interior
Size range
Max. width 5000 5000
Max.. height 5000 5000
Speed with control
Max. opening (m/s) 1.5 2.0
Closing approx. (m/s) 0.8 0.8
  UPVC, aluminium profiles UPVC, spring steel wind locks with lateral twin rollers
Temperature range +5°C to +40°C +5°C to +40°C
Fabric thickness (mm) 1.5 1.5
Vision panel thickness (mm) 2.0 2.0
Fly protection curtain
Curtain Colours
RAL 1018 Zinc yellow
RAL 2004 Pure orange
RAL 3002 Carmine red
RAL 5010 Gentian blue
RAL 7038 Agate grey
Emergency opening
Emergency crank handle
Emergency hand chain
Automatic door opening via UPS in case of power failure


● = Standard ◌ = Optional
