Robust Tuff-Dor 4.1 SR4 Steel Doorset

The Robust Tuff-Dor 4.1 is a made-to-order, high-security steel doorset engineered for locations where a successful forced entry would have critical consequences. Certified to LPS 1175 SR4 (Issue 7) and approved by Secured by Design, it is designed to withstand sustained attacks using heavy-duty tools, providing one of the highest practical levels of physical protection available in a steel door assembly.

Positioned above SR2 and SR3 solutions, Tuff-Dor 4.1 is intended for high-risk environments such as utilities infrastructure, data centres, defence and government premises, and high-value commercial sites. It is not simply a strengthened personnel door; it is a purpose-built security barrier that forms a key part of the overall building protection strategy.

Heavyweight 66mm Security Construction

At the heart of the Tuff-Dor 4.1 is a substantial 66mm thick, double-skinned steel leaf, mounted into a factory-fitted outer steel sub-frame to create a rigid, unified structure. Each door leaf is hung on six heavy-duty hinges and secured on the hinge side by nine hooked dog bolts, locking the door into the frame even if the hinges are attacked.

The leaf incorporates a solid core with additional internal reinforcement at strategic points, significantly increasing resistance to levering, prying, cutting and impact. The result is a very heavy doorset that feels noticeably more substantial than standard commercial steel doors, offering genuine delay against determined, tool-assisted intrusion.

Materials, Corrosion Resistance and Finishes

Tuff-Dor 4.1 is manufactured using Zintec steel for the door leaf as standard, providing excellent base-level corrosion protection and an ideal surface for high-quality powder coating. For external applications and long-term durability, the doorset can be specified in Magnelis® steel, enabling anti-corrosion warranty cover of up to 10 years in appropriate environments (excluding C4/C5 locations).

Doors can be supplied in a full range of polyester powder coated (PPC) finishes to standard RAL or BS colours, with stainless steel options available for particularly harsh or architecturally sensitive sites. This allows the Tuff-Dor 4.1 to deliver extremely high security while still blending with façade design and brand requirements.

Fire Safety and Hardware Options

To support safe evacuation as well as high security, Tuff-Dor 4.1 can be configured with a wide choice of hardware, including panic and emergency escape systems tested to BS EN 1125 and BS EN 179. This means the door can provide fast, compliant egress from inside while maintaining a robust defence against external attack.

Single and double leaf configurations are available, with overall frame sizes up to approximately 1430mm wide x 2930mm high for single doors and 2600mm wide x 2930mm high for double doors, making the range suitable for large plant access, equipment rooms and main secure entrances. Where required, fire-rated variants (Tuff-Dor 4.1 FD60) can provide 60 minutes of fire resistance within a defined specification, combining life safety and security in one doorset.

Applications for Highest-Risk Sites

The Tuff-Dor 4.1 is intended for scenarios where SR2 or SR3 doors may not provide sufficient delay or resilience. Typical uses include sensitive service entrances, critical infrastructure enclosures, secure stores for high-value goods, and locations with slow response times where extended resistance to attack is essential.

With its combination of SR4 certification, solid-core 66mm construction, multi-point mechanical retention and proven corrosion protection, Tuff-Dor 4.1 is a compelling choice when a project demands one of the toughest steel doorsets available, backed by recognised third-party testing and long-term warranty support.

The Robust Tuff-Dor 4.1 is aimed at high-risk UK environments where a successful break-in would have major financial, operational or safety consequences. LPS 1175 SR4 doors are typically used where attackers are expected to be well-equipped and persistent, and where security consultants or insurers specify a tested SR4 solution.

Critical Infrastructure & Utilities

• Electrical substations, switching stations and power distribution compounds operated by DNOs/IDNOs.
• Water treatment works, pumping stations and remote control buildings vulnerable to delayed response times.
• Energy generation sites, including CHP plants and renewable energy control rooms, requiring robust physical protection.

Data Centres & Digital Infrastructure

• Main secure entrances and service doors to Tier III/IV data centres and colocations.
• Server rooms, comms rooms and network hubs within larger campuses, where SR4 supports physical security requirements such as ISO 27001.
• Plant and cooling equipment rooms protecting critical IT and power infrastructure.

Government, Defence & Justice

• High-risk government buildings and secure ministries where enhanced delay against forced entry is essential.
• Police, MOD and security service facilities, including armouries and secure evidence or weapons stores.
• Court buildings and custody environments needing controlled, attack-resistant access routes.

Cash, Valuables & High‑Value Commercial

• Cash handling centres, CIT depots and bullion or ATM replenishment facilities.
• Pharmaceutical storage areas, high-value R&D labs and chemical stores with strict security and compliance requirements.
• Luxury goods warehouses, bonded warehouses and secure loading bays for high-value stock.

Museums, Galleries & Iconic Venues

• Museums, galleries and archives holding high-value or irreplaceable artefacts requiring extended delay to support police response.
• Iconic or publicly prominent buildings assessed as potential targets for sophisticated attack.
• Back-of-house secure doors where public access is nearby but unauthorised entry must be rigorously controlled.

Door Leaf

• Infill: Honeycomb or mineral wool core with integral internal reinforcement for increased rigidity and resistance to attack.
• Vision Panels: Available as single or multiple panes; maximum sizes are dependent on hardware selection and required security performance.
• Louvres: Punched and/or bladed cartridge options available where ventilation is needed without compromising overall security.

Door Structure & Dimensions

• Minimum Overall Dimensions:
  • Single Door: 600mm (W) x 1000mm (H)
  • Double Doors: 900mm (W) x 1000mm (H)
• Maximum Overall Dimensions:
  • Single Door: 1430mm (W) x 2930mm (H)
  • Double Doors: 2600mm (W) x 2930mm (H)
• Side Panels: Optional fixed side panels available where wider secured screens are required.
• Over Panels: Available as fixed or hinged over panels to accommodate increased opening heights or access requirements.

Door Frame

• Frame Profile: 110mm rebated frame section providing a secure stop and improved weather and attack resistance.
• Material: 2.0mm Zintec steel as standard frame construction.
• Frame Infill: None as standard.
• Hinges: 126mm lift-off hinges or Grade 13 butt hinges, with 6 hinges per door leaf.
• Dog Bolts: 9 security dog bolts per leaf, locking the leaf into the frame on the hinge side to resist levering even if hinges are attacked.

Door Certification & Performance

• Security Rating: LPS 1175 SR4 (Issue 7) certified for high-level resistance to forced entry.
• Fire Rating: None (non-fire rated as standard).

Installation Guide: Robust Steel Doorsets

Robust steel doorsets are engineered with one clear goal: to be the easiest and fastest steel doors to install on the market. Whether you are fitting a single personnel door or a large double fire exit, our "Single Fix" design and adjustable frame system remove the complexity of traditional on-site joinery.

Delivered for Speed

To minimize site time and disruption, we supply our doorsets in the most installer-friendly format possible:

• Single Doors: Delivered fully assembled. The leaf is pre-hung in the frame with hardware (locks, panic bars, closers) factory-fitted and tested. Simply unwrap, position, and fix.
• Double Doors: For ease of manual handling, larger double doorsets may be supplied with the leaves separate from the frame. However, the frame is pre-prepared with all hinge points and striker plates for rapid on-site assembly.

The "Easy-Fit" Adjustable System

Structural openings are rarely perfect. All Robust doorsets feature a unique built-in adjustment system that handles site imperfections without the need for fiddly packers or shims.

1. Adjustable Fixing Feet

Each jamb is fitted with 4 adjustable fixing feet (8 per single door, 8-12 per double). These allow you to:

• Level the frame quickly using a 12mm hex key (supplied).
• Wind the feet out to grip the structural reveal securely, holding the frame in place while you check for plumb.
• Create a rock-solid fixing point without distorting the frame profile.

2. Variable Sub-Frame

The steel sub-frame features a "C" section tolerance channel that accommodates wall variations of -0mm to +30mm. This ensures:

• If your brickwork is uneven or the opening is slightly tapered, the frame expands to fill the gap.
• You achieve a continuous, secure fixing into the substrate without large, unsightly gaps to seal.

General Installation Steps

Step 1: Positioning

• Single Doors: Place the fully assembled unit into the structural opening.
• Double Doors: Assemble the frame (if supplied in parts) and position it in the opening first. Ensure the header is level before hanging the leaves.

Step 2: Adjustment & Levelling

• Use the 12mm hex key to wind out the adjustable feet until they grip the wall.
• Critical Check: Ensure the hinge jambs are perfectly plumb (vertical) in both planes using a long spirit level. If the frame is twisted, the door will not latch correctly.
• For double doors, ensure the frame header is perfectly level to prevent the leaves from misaligning at the meeting point.

Step 3: Fixing

• Drill through the center of the adjustable feet into the masonry or steelwork.
• Secure with appropriate fixings (e.g., 100mm x 10mm concrete bolts or heavy-duty tech screws).
• Test: Open and close the door(s) to check for smooth operation and correct latching before final tightening.

Step 4: Sealing

• Apply a fire-rated silicone or intumescent mastic around the entire perimeter of the frame (internal and external) to ensure fire and weather integrity.
• If a threshold is fitted, ensure it is bedded on sealant to prevent water ingress.

Handling Advice

• Weight Warning: Steel doors are heavy. A single leaf can weigh 50kg - 80kg.
  • Single Doors: Use a mechanical lifter or a two-person team.
  • Double Doors: We strongly recommend separating the leaves from the frame before moving to the installation point to reduce lifting weight.
• Storage: Always store doorsets upright on timber bearers in a dry, covered area. Never lay them flat on uneven ground or expose them to rain before installation.

Samson Doors Warranty (Robust UK Products)

As a premier supplier of Robust UK steel doorsets, Samson Doors provides a comprehensive warranty that covers your product against manufacturing defects and corrosion. This guarantee assumes that the doorset has been installed, used, and maintained in accordance with the manufacturer's instructions.

Anti-Corrosion Warranty

Thanks to the superior Magnelis® steel construction used by Robust UK, we are able to offer an industry-leading anti-corrosion warranty. The length of this warranty depends on the environmental classification of the installation site:

• Magnelis® Steel Doors:
  • 10-Year Warranty: For locations classified as C1 to C3 (Low to Medium pollution/humidity, e.g., rural areas, standard urban sites).
  • 5-Year Warranty: For locations classified as C4 (High pollution/industrial areas or coastal zones).
  • 3-Year Warranty: For locations classified as C5 (Very high pollution/marine environments).
• Aluzinc Steel Doors:
  • 24-Month Warranty: Standard cover for Aluzinc models.
  • Extended Warranty: Available if an enhanced Polyester Powder Coated (PPC) finish is specified at the point of order.

Important Exclusion: The anti-corrosion warranty applies specifically to the door leaf and frame components manufactured from Magnelis®. Ancillary components (such as vision panels, louvres, and handles) are excluded unless additional protection was agreed upon prior to manufacture.

Manufacturing & Component Warranty

• Doorset Structure: 24-Month Warranty against manufacturing defects (e.g., bond failure, weld failure).
• Hardware & Ironmongery: 12-Month Manufacturer's Warranty on all locks, handles, closers, and panic hardware, subject to normal use and maintenance.

Conditions of Warranty

For any claim to be valid, the following conditions must be met:

1. Maintenance Log: A documented cleaning and maintenance regime must be kept, recording the frequency of cleaning and the products used. This log must be submitted with any warranty claim.
2. Correct Installation: The product must have been installed correctly according to the provided fitting instructions (including correct frame adjustment and sealing).
3. Reporting Period: Any manufacturing defects visible on delivery (e.g., scratches, dents) must be reported to Samson Doors in writing within 3 working days of receipt, accompanied by photographic evidence of the goods on the original pallet.

Warranty Exclusions

The warranty does not cover defects or damage resulting from:

• Abuse & Neglect: Damage caused by misuse, vandalism, or lack of routine maintenance (e.g., failure to lubricate hinges/locks).
• Chemical Damage: Use of corrosive cleaning agents, solvents, or abrasive pads on the door finish.
• Installation Errors: Issues arising from poor fitting (e.g., frame twisted out of square, insufficient fixings).
• External Factors: Damage from storms, floods, or impacts not considered normal usage.
• Unauthorised Modifications: Fitting of third-party hardware or cutting into the door leaf/frame without prior written approval.
• Fair Wear & Tear: Normal degradation of consumable parts (e.g., seals, keys) over time.

Claims Procedure

In the unlikely event of a fault, please follow this procedure:

1. Contact Samson Doors in writing immediately upon discovery of the defect.
2. Provide your original order reference, a detailed description of the issue, and clear photographs.
3. If required, the defective part may need to be returned for inspection.
4. Where a valid claim is accepted, Samson Doors (in conjunction with Robust UK) will repair or replace the defective component or product at our discretion.

A steel doorset is always ordered by the OVERALL dimensions including the door leaf and outer sub fixing frame with no tolerances allowed for. Most people would generally allow 5mm tolerance all the way around the door, but it all depends on how square or true your aperture is on site.

This means if your structural opening size is measured as 1000mm width and 2100mm height the door and frame ought to be 990mm wide and 2090mm high with the frame and any threshold included.
