seceuroshield 3801 insurance approved security shutters

SeceuroShield 3801 High Security Insurance Approved Security Shutters

The SeceuroShield 3801 provides a strong secure fitting to ensure your goods stay within the property and criminals are kept out. It has a strong secure foundation and is supplied with either a lock in the bottom slat or a pair of bullet locks attached to the guide rails The SeceuroShield 3801 is an Insurance Approved design by SWS. Approval has been gained as a result of independent testing to Loss Prevention Standard (LPS) 1175 Security Rating Classification 1.

REMOVING THE GUESSWORK FROM PRODUCT EVALUATION AND SELECTION
How can you know which products are truly resistant to physical attack?
Appearance may suggest security, but can you be sure that a device does not contain a design flaw that will allow rapid access to the ingenious burglar? Specifiers, end-users, the police and insurers are increasingly demanding physical security products that carry an independent stamp of compliance and quality assurance.

 TESTED AND APPROVED TO LPS 1175
The Loss Prevention Certification Board (LPCB) is the UK’s leading independent certification body for fire and security products operating an approval scheme to LPS 1175. Approval and certification is based on the testing of a product’s performance and the manufacturer’s quality management systems being in accordance with ISO 9002. Installation procedures are also defined to a specific, high standard, ensuring the product performance is not compromised by sub-standard installation. These specialist products should only ever be attached to structurally sound openings such as masonry, brick, steel or timber, moreover the type and frequency of fixings required is very precise. LPS 1175 is the only meaningful benchmark for gauging actual resistance in the face of a determined attack. Passing the test regime is a tough and lengthy process that has been successfully completed by the SeceuroShield 3801. Under the stringent conditions of a comprehensive test regime, SeceuroShield 3801 is subjected to a variety of assaults from equipment commonly used for vandalism and breaking and entering, in order to ascertain its burglary resistance to physical attack.

LPCB approval and certification gives assurance of the SeceuroShield 3801's construction and consistent performance to an internationally recognised standard. Take the guesswork out of product selection - use tested and approved products from the SWS range.



Seceuroshield 3801 in green installed onto a business property

THE POLICE PREFERRED SPECIFICATION
As a further reinforcement of the products performance, the SeceuroGuard 1001 retractable security gate has successfully undergone Secured by Design evaluation and is able to display the “Police Preferred Specification” mark. Secured by Design identifies technical standards and evaluations which test the competence of security products and their resistance to criminal attack. The tests and evaluations are carried out by UKAS approved test houses.






H40/S Guide Rail


GUIDE RAILS

The SeceuroShield 3801 uses the H40/S guide rail. It is constructed with extruded aluminium with an integral box section to facilitate fixing and reinforced with steel reinforcement sections at the bottom. Available in stock colours of white and dark brown, the SeceuroShield 3801 shutter and guide rails can be powder coated to alternative standard RAL or BS colours at extra cost and, should this be required, we would be pleased to prepare a quotation. The dimensions of this guide rail are 70mm wide x 27mm deep and are supplied with a 5mm guide brush as standard. The H40/S guide rail is also available with bullet locks as an additional extra.

FOR RETAIL PREMISES

The Seceuroshield 3801 offers a low visual impact when open which make them a key requirement for retail outlets. The shutters use a 38mm double-walled extruded aluminium slat which coils very tightly into a range of compact boxes (165mm-250mm) which helps to decrease their visual presence.

FOR BUSINESS PREMISES

Offering a high level of security is key to a business, and the SeceuroShield 3801 offers this in abundance as shown through the LPS 1175 testing certificate.

STOCK COLOURS

The SeceuroShield 3801 has 3 stock colours for the curtain/slats. These are White (RAL9010), Brown (RAL8014) and Cream (RAL 1015). The boxes and guides come in White (RAL9010) and Brown (RAL8014). The SeceuroShield 3801 can also be powdercoated to colour code your business' appearance.

SECURITY FEATURES

Standard shutters lock automatically at the top when fully lowered and this product must also be supplied with either a lock in the bottom slat or a pair of bullet locks attached to the guide rails. The bottom section of the shutter box is riveted after installation. The fixing screw heads are rendered unusable and are concealed behind cover caps. The curtains are supplied with anti-vandal wind end locks as standard. The extruded aluminium bottom slat is reinforced with a steel angle and the high security H40/S guide rails are reinforced with steel plates at the base.

SLATS

Description: Seceuroshield 3801 is a double skin extruded aluminium non-vented slat fitted with anti-vandal wind endlocks.
Common Use: Domestic, retail and commercial properties requiring an above average level of security.
Dimensions: Nominally 38mm high x 9mm thick.
Weight: 8kg per square metre.
Stock Colours: White, brown or cream. Bottom slat - white, dark brown.




Min Width: 900mm
Max Width x Height:  3000mm x 4000mm
Max Area: 12sqm
Material: Extruded Aluminium / 8kg/m²

SeceuroShield3801 38mm double-walled extruded aluminium slat
  Profile of 38mm slat

SHUTTERBOX


Construction: Roll formed aluminium in two sections; top and bottom boxes. Bottom box removable for installation and maintenance and chamfered at 45°.
Box Ends: The shutter box is assembled on steel endplates.
Box Sizes: Clear opening height (to underside of box):
1535mm, box size 165mm
1820mm, box size 180mm
2595mm, box size 205mm
3750mm, box size 250mm


INSTALLATION

Guide Rails: Each guide rail must have a minimum of 5 fixings per guide rail (irrespective : of size). The minimum required fasteners are No.12 x 2 ½ “ screws and plugs for masonry and M8 fasteners with 10mm engagement for steel.
Shutterbox: The shutterbox is fixed at each end and 1000mm centres if over 2000mm wide. A minimum of 2 fixings per end plate are required.
Finishing: External shutters require a silicone seal between the shutter and the wall along the top of the box and down the side of the guide rails.
